Vertical Mast Lift 6.55m SJ16E
- Type
- Electric
- Model
- SJ16E
- Made in
- USA/ China
SKYJACK is a Canadian company founded in 1985, known for making reliable and high-quality aerial work platform equipment. Over the years, Skyjack became an industry leader by providing machine features that combine durability, quality, and ease of maintenance. Quality and reliability are the hallmarks that have given Skyjack scissor lifts a solid reputation as the best and one in three scissor lifts sold worldwide is a Skyjack.
By using proven technology and keeping designs simple, Skyjack ensures that all machines are reliable, easy to service and maintain for customers.
This equipment has many different models,
for more details please contact us.
- Performance: Variable speed front 2-wheel electric drive, 25% gradeability, 90° steering with zero inside turning radius, drivable at full height (platform retracted).
- Controls: Proportional drive & lift controls, onboard visual diagnostics, shroud-style impact-resistant control box.
- Platform: 16” traversing platform, lanyard points, half-height spring-hinged entry gate, 110V AC outlet with GFI.
- Power: 24V DC system, 2 x 12V batteries, low voltage protection.
- Safety: Overload sensing, tilt alarm (2.5° x 1.5°) with drive/lift cut-out, fixed pothole protection, dual holding brakes, all-motion alarm, operator horn.
- Design: Solid rubber non-marking tires, multistage lift cylinders, removable oil filter, forklift pockets, lift rings/tie-downs, telematics ready.
- Warranty: 2-year Gold Leaf, 5-year structural.
※The table can be viewed by scrolling left and right.ecification
Specifications of Vertical Mast Lift SJ16E
| Model | SJ16E |
| Max. Working Height (A) | 6.55 m |
| Raised Platform Height (B) | 4.72 m |
| Lowered Platform Height (C) | 0.76 m |
| Max. Working Capacity | 272 kg |
| Overall Width (D) | 0.77 m |
| Overall Length (E) | 1.37 m |
| Stowed Height (Top of Mast) (F) | 1.88 m |
| Platform Width (G) | 0.69 m |
| Platform Length (H) | 0.91 m |
| Step in Height (First Step) (I) | 0.46 m |
| Wheelbase | 1.12 m |
| Gradeability | 25% |
| Weight | 931 kg |
